Versatile I/O Capabilities
Analog Inputs
- • 4 channels supporting 4-20mA and 0-10V DC
- • 16-bit resolution for precise measurements
- • Up to 10 samples/second
- • ±0.1% accuracy
Digital I/O
- • 4 digital inputs with 12-24V DC range
- • 2500V isolation
- • 4 digital outputs with Form C relays
- • Rated for 5A at 230V AC
Communication
- • 4G LTE CAT-M1 with 2G fallback
- • Wi-Fi 802.11 b/g/n with mesh networking
- • Optional RS485 Modbus interface
- • Bluetooth for local configuration
Robust Power Management
Battery Backup
Optional battery ensures continuous operation during power outages. Graceful shutdown and auto-restart protect your data.
Efficient Design
Low power consumption of <5W typical. Sleep mode support for extended battery life in remote installations.
Flexible Input
Wide 12-24V DC input range. Compatible with various industrial power supplies and solar panel systems.
Engineered for Harsh Environments
Robust Construction
IP55 rated enclosure protects against dust and water ingress. Optional IP65 rating available for extreme conditions.
Wide Temperature Range
Operates reliably from -20°C to +70°C. Ideal for challenging industrial environments.
Security Features
Encrypted Transmission
End-to-end encryption protects your sensitive industrial data in transit. Supports latest TLS protocols.
Access Control
Role-based authentication ensures only authorized personnel can access device settings and data.
